AVMATRIX Shark S4 4-Channel 3G-SDI/HDMI Video Switcher

Product Highlights

• 4-channel video switcher
• 2 x 3G-SDI & 2 x HDMI inputs
• 1 x HDMI multiview & 2 x HDMI PGM out
• 1 x USB-C out for capture & streaming
• Supports up to 1080p60 video in/out
• 1 x LAN for control input & streaming
• T-Bar, Auto & Cut transitions
• SD Card/USB-A recording, 2 x mic inputs
• Audio mixing, multiview output
• Adjustable PiP size & positioning

Overview of the Shark S4 4-Channel 3G-SDI/HDMI Video Switcher

The AVMATRIX Shark S4 4-Channel 3G-SDI/HDMI Video Switcher is a livestreaming and broadcasting gadget that you can use to switch up to 2x 3G-SDI and 2x HDMI video inputs. To capture or stream use the USB-C output from the switcher to your computer using software like OBS, Skype, Teams, VLC, Zoom, or vMix. Shark S4 supports up to 1080p60 video input and output with embedded audio and offers audio mixing using the two analog stereo 3.5mm mic/line inputs and output along with the embedded audio. Switcher control options include push buttons, a T-bar, and IP control via the LAN port.

Features

• SD Card and USB Recording - Record your feed to a flash drive or SSD in MP4 format using the USB-A output port, or via the built-in SD card recording slot.
• Live stream via ethernet - an included LAN port supports IP streaming via RTMP or SRT protocols to such platforms such as YouTube, Skype, Facebook, Twitch, and more.
• Enhanced chroma key
• Import up to 39 default patterns, 16 imported images, 16 captured images, and two color generators via USB
• PiP, PoP, logo overlay, transition effects

In the Box

• AVMATRIX Shark S4 3G-SDI/HDMI video switcher
• USB-A to USB-C Cable
• 12V Power Supply
• Tally Connector
